Breakwater
details 12

International
Breakwater
Directory

  12 Algeria - Arzew      (Lat: 35.82 Lon: -0.254 - click for map)

   North breakwater

   Rubble mound

   Rehabilitation

Main breakwater data:


Length (m) 0   owner Port of Arzew
Waterdepth (m) 0   contractor Boskalis
Construction time (years) 0   consultant Nedeco
Start date (year) 1986   Hydraulic Laboratory
Completion date (year) 1986   comments
Construction costs($106) 0

Design criteria


Hs (m) 0
Tz/Tp (s) 0/0

slope/crest info
front slope 1:0 65 ton Antifer
rear slope 1:0 0
crestheight (m) 0
crest/caisson width (m) 0
wallheight (m) 0
no picture available
click on picture for enlargement
no drawing available


  Reference documents:

1991 - Boskalis - Reference sheet Arzew; - - ;
