Breakwater details

International
Breakwater
Directory

29 Netherlands - Scheveningen      (Lat: 52.102 Lon: 4.256 - click for map)
Zuiderdam

Rubble mound
Breakwater extension

Main breakwater data:
Length (m) 600   owner Rijkswatertaat
Waterdepth (m) 9   contractor Boskalis
Construction time (years) 3   consultant
Start date (year) 1969   Hydraulic Laboratory Deltares
Completion date (year) 1971   comments
Construction costs($106) 120
Design criteria
Hs (m) 6
Tz/Tp (s) 12/0
slope/crest info
front slope 1:1.5 25 ton Cubes
rear slope 1:1.5 25 ton Cubes
crestheight (m) 4
crest/caisson width (m) 0
wallheight (m) 0
no picture available
click on picture for enlargement
no drawing available



Reference documents:
Roos, A [1971] Scheveningen uit de branding, Land+Water3-34-40 HR Wallinford 10/79
Zipfile with pictures (copyright pictures CHS)


This is a database prepared by HR Wallingford and TU Delft with the assistance of the international breakwater community and has been made freely available for the benefit of breakwater designers, contractors owners and developers worldwide. The database is subject to regular updating as information becomes available, however the development and maintenance of this database relies primarily on information supplied or published by third parties and no responsibility can be taken for the accuracy of data supplied.
